Mortise Passage Lock 72ZL Series
Features
• BS EN 12209 / DN 18251 / EN 1634-1
• Fire Rated
• CE Certified
• Suitable for Fire / Non-Fire Rated Steel & Wooden doors
Additional Information
Models
SZi-5572ZL : X=55mm
SZi-6072ZL : X=60mm
SZi-6572ZL : X=65mm
Accessories
- Strike pockets (Optional)
- Lock and strike fixing screws
Technical Data & Characteristics
| Center Distance | 72mm |
| Backset | 55/60/65/70/80mm |
| Lock case | Galvanized Steel |
| Latch | SS304 |
| Follower | SS304 8 x 8mm |
| Forend Plate | SS304 (SS316 optional) |
| Forend Type | Square edge or Round edge |
| Striking Plate | SS304 (SS316 optional) |
| Latch Handing | Field Reversible |
Dimension of Appearance
