    Mortise Lock with Roller Bolt 72ZR Series_dwg

    Mortise Lock with Roller Bolt 72ZR Series

    Features
    • Suitable for Fire / Non-Fire Rated Steel & Wooden doors
    • Compatible with Euro profile cylinder
    • Double dead bolt throw

    Models

    SZi-5572ZR : X=55mm
    SZi-6072ZR : X=60mm

    Accessories

    • Strike pockets (Optional)
    • Lock and strike fixing screws

    Technical Data & Characteristics

    Center Distance 72mm
    Backset 55/60mm
    Lock case Galvanized Steel
    Roller Latch SS304
    Dead Bolt SS304
    Forend Plate SS304 (SS316 optional)
    Forend Type Square edge or Round edge
    Striking Plate SS304 (SS316 optional)
    Latch Handing Field Reversible

    Dimension of Appearance
