    Mortise Bathroom Lock 78ZWC Series_dwg

    Mortise Lock 85Z Series

    Features
    • BS EN 12209 / DN 18251 / EN 1634-1
    • Fire Rated
    • CE Certified
    • Suitable for Fire / Non-Fire Rated Steel & Wooden doors
    • Compatible with Euro profile cylinder
    • Double dead bolt throw

    Models

    SZi-4585Z : X=45mm
    SZi-5085Z : X=50mm
    SZi-6085Z : X=60mm

    Accessories

    • Strike pockets (Optional)
    • Lock and strike fixing screws

    Technical Data & Characteristics

    Center Distance 72mm
    Backset 45/50/60mm
    Lock case Galvanized Steel
    Latch SS304
    Dead Bolt SS304
    Follower SS304 8 x 8mm
    Forend Plate SS304 (SS316 optional)
    Forend Type Square edge or Round edge
    Striking Plate SS304 (SS316 optional)
    Latch Handing Field Reversible

    Dimension of Appearance
